TÜV Rohs Conform

Heat Shrink Tube Box 20m Red 0.8mm / 0.45mm

delivery time: 2 - 3 Tage nach unseren Betriebsferien ab 06.01.2025
Product.Nr.: 461201
weight: 0.115 kg
Manufacturer: Import

Business customers graduated prices after
registration in the login with your VAT ID.

7,20 EUR
(0,36 EUR pro Meter) incl. 19 % VATexcl. shipping costs

Discount

Quantity Single price Saving pro Meter
1 7,20 EUR 0,36 EUR
>= 2 6,72 EUR -7 % 0,34 EUR

Box with 20 m red shrink tube Ø 0.8 mm

Shrink tubing box, red shrink tubing Ø 0,8mm before shrinkage, shrink ratio 2: 1

Heat Shrink Tube made of radiation-crosslinked polyolefin, color red, shrinkage rate 2: 1, thin-walled and rapidly shrinking from + 85 ° C. The shrink tube is flexible, flame-retardant and halogen-free.
This shrink tube is UL 224, VW-1, CSA certified, RoHS-compliant and suitable for long-term use at temperatures from -55 ° C to + 135 ° C.

Just pull required length ofl the shrink sleeve out of the box, cut it off and process it. The rest remains well protected in the practical donor box until the next use.
Except in red, this high-quality heat shrink tube made of polyolefin is available in a further seven colors.

From 0.8 mm diameter before shrinkage, the well graded pallet is up to 150 mm Ø. This corresponds to a flat dimension of 235 mm.

We also cut all available sizes as yours individual meter-goods from the manufacturer's roll.

In the practical unwind box, shrink tubes up to Ø 25.4 mm are available. Above this size as yours individual cut good and on manufacturer-roll.

Available standard colors:
Black, Transparent / Clear, Red, Yellow, Blue, Green, Orange, White



Specifications Heat Shrink Tube

Color  Red
Material  Cross-linked polyolefin
Material properties  Thin-walled, flexible
Featuring  Box with 20m
Inner Ø before shrinking  0.8mm
Inner Ø after total shrinking  0.45mm
Wall thickness after complete shrinkage  0.35mm
Shrink Ratio  2:1
Continuous Operating Temperature  -55°C bis +125°C
Shrink Temperature  +85°C
Flammability  Flame-retardent, Halogen-free
Approvals / Specifications  UL, CSA, VW-1
Features  RoHS Complient, Halogen free
